UV LED Spot Curing System NSC4

The NSC4 high-intensity UV LED curing system consists of a controller and up to four independently controlled LED lamps. This system offers a variety of focusing lenses to provide high UV intensity of up to 14W/cm². With the optional wavelengths of 365nm, 385nm, 395nm and 405nm, it is compatible with a wide range of materials used in the curing process.
With its compact design, the NSC4 can be easily integrated into the production line, allowing for precise and efficient curing, ensuring optimal results. It is suited for a variety of applications in the medical, electronics, automotive, optical and so on.

Inquiry

UV LED Spot Curing System Featured Image

Technical Description

Model No.	NSC4
UV Power Adjustable Range	10~100%
Irradiation Channel	4 channels; Independent running each channel
UV Spot Size	Φ3mm, Φ4mm, Φ5mm, Φ6mm,Φ8mm, Φ10mm,Φ12mm,Φ15mm
UV Wavelength	365nm,385nm, 395nm, 405nm
UV LED Cooling	Natural / Fan cooling

Looking for additional technical specifications? Contact with our technical experts.

Leave your message

UV Applications

https://www.uvet-adhesives.com/uv-curing-spots/

The NSC4 UV LED curing system is an efficient curing solution that delivers high UV intensity of up to 14W/cm². With optional wavelengths of 365nm, 385nm, 395nm and 405nm, this system offers flexibility and compatibility with a variety of materials used in the curing process. This versatility enables precise and efficient curing, ensuring that different types of materials can be cured with maximum efficiency.

One of the key features of the NSC4 is its seamless integration into production lines. Its compact design and user-friendly interface make it easy to install and operate, allowing for a smooth transition into existing manufacturing processes. What's more, this versatile curing system is suitable for a variety of applications in different industries. It can provide reliable results for bonding, fixing or encapsulating of components in the electronic, optical or medical-technical sector.

In addition, the NSC4 is equipped with a variety of focusing lenses, allowing the system to deliver high UV intensity precisely where it is needed. This level of precision ensures that the curing process is optimized for each specific application, resulting in exceptional quality and consistency.

In summary, the NSC4 UV LED curing lamp represents a major advance in curing technology. Its high UV intensity, multiple wavelength options, seamless integration and wide range of applications make it a valuable asset for manufacturers looking to optimize their curing process.
