UV LED Lamps UVH50 & UVH100

The UVH50 and UVH100 headlamps are compact, portable UV LED lamps designed for NDT. These lights feature antioxidant black light filters that minimize visible light while enhancing UV output. At a distance of 380mm, the UVH50 offers a 40mm irradiation diameter with an intensity of 40000μW/cm², and the UVH100 provides a beam diameter of 100mm with an intensity of 15000μW/cm².
Equipped with a durable strap, these headlamps can be worn over a helmet or directly on the head for hands-free operation. In addition, they can be adjusted in different angles for flexible use in a variety of inspection environments, making them ideal for a wide range of professional inspection applications.

Inquiry

UV LED Lamps UVH50 & UVH100 Featured Image

Technical Description

Model No.	UVH50	UVH100
UV Intensity@380mm	40000µW/cm²	15000µW/cm²
UV Beam Size@380mm	Φ40mm	Φ100mm
UV Wavelength	365nm
Weight (With Battery)	About 238g
Running Time	5 Hours / 1 Full Charged Battery

Looking for additional technical specifications? Contact with our technical experts.

Leave your message

UV Applications

https://www.uvet-adhesives.com/uv-inspection-lamps/

UVET's UV LED headlamps are specialised inspection tools designed for non-destructive testing (NDT), featuring a compact and adjustable angle design. These headlamps not only free the hands but also provide reliable illumination in various environments, significantly enhancing work efficiency. Whether used in industrial inspection or automotive repair, the UV LED headlamp demonstrates exceptional practicality.

To meet to different UV intensity and beam requirements, UVET offers two models of UV LED inspection lamps: the UVH50 and UVH100. The UVH50 provides high-intensity irradiation for detailed inspections, while the UVH100 features a broader beam for overall observation. What's more, the adjustable angle makes it easy to focus the beam on specific areas, ensuring that every detail can be clearly detected.

In industrial applications, these headlamps are effective in identifying substances that may be missed by traditional light sources, such as oil, cracks and other potential defects. This capability makes them an indispensable tool in industrial inspections, building assessments and automotive maintenance. Even in dark or low-light environments, details requiring attention are clearly visible, ensuring high quality work.

Additionally, the lightweight design of these lamps makes them ideal for extended wear. Whether working in tight spaces or conducting outdoor inspections, the headlamp can be comfortably secured, allowing hands to remain free for other tasks. This design not only increases productivity but also reduces fatigue, making it a reliable solution for inspection.
